| Model： | LY-S3200P |
| Name： | 32inch professional CCTV LCD Monitor |
| Description： | 1.The professional level A + LCD display, low power consumption, low calorific value, flicker-free, low radiation 2.The driver board, professional image processing was used in industrial parts meet the long time continuous use 3. |
- Attribute
- Picture
- Customer
|
Product name |
32inch professional CCTV LCD Monitor |
| Model No. | LY-S3200P |
| Display area | 699.58mm(W)×393.58mm(H) |
| display scale | 16:9 |
| light source Type | LED |
| Maximum resolution | 1366×768 |
| Display color | 16.7M |
| Pixel Pitch(mm) | 0.297(H)×0.297(V) |
| (nits)Brightness (nits) | 400cd/m2 |
| Contrast | 3000:1 |
| Visual angle | 178°/178° |
| Response time | 5ms |
| field frequency | 50Hz、60Hz、70Hz |
| BNC input | 3 |
| YPbPr input | 1 |
| DVI input | 1 |
| VGA input | 1 |
| HDMI input | 1 |
| BNC output | 2 |
| Color system | PAL/NTSC/SECAM |
| Menu language | Chinese/English for option |
| Power supply | AC100V-240V,50/60Hz |
| Maximum power consumption | <160W |
| Standby power consumption | <5W |
| Body dimension(Lx W x H)mm | 773.6mm×470mm×118mm |
